Design
Safety: UL 60950-1 & CSA 60950-1, CB IEC 60950-1 & EN 60950-1, UL/CUL
Rack mounting: Yes
Product colour: Grey
LED indicators: Yes
Stackable: Yes
Power
AC input frequency: 50 - 60 Hz
Output current: 1.5 A
Power consumption (typical): 35 W
AC input voltage: 100 - 240 V
Security
DHCP features: DHCP snooping, DHCP relay
IGMP snooping: Yes
BPDU filtering/protection: Yes
DoS attack prevention: Yes
Static port security: Yes
SSH/SSL support: Yes
Authentication: MAC-based authentication, Web-based authentication
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -40 - 70 °C
Management features
Quality of Service (QoS) support: Yes
ARP inspection: Yes
Traffic classification: Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Height: 44 mm
Width: 440 mm
Depth: 315 mm
Weight: 3.7 kg
Network
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ag, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ah, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1p, IEEE 802.1x, IEEE 802.3u, IEEE 802.1w
Full duplex: Yes
VLAN support: Yes
10G support: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Virtual LAN features: MAC address-based VLAN, IP subnet–based VLAN, Voice VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN
Performance
Firmware upgradeable: Yes
Flash memory: 128 MB
Internal memory: 256 MB
Mean time between failures (MTBF): 904213 h
sFlow: Yes
Telnet: Yes
Physical stacking (units): 8
Packaging data
Package weight: 5.3 kg
Package type: Box
Package width: 590 mm
Package height: 133 mm
Resource CD: Yes
Package depth: 390 mm
Rubber feet: Yes
Packaging content
Cables included: AC, LAN (RJ-45)
Quick start guide: Yes
Rack mount kit: Yes
Protocols
Supported network protocols: IPv4/IPv6
GARP VLAN Registration Protocol (GVRP): Yes
Management protocols: CLI/WEB, Telnet/SNMP v1/v2/v3, RMON I,BOOTP/DHCP, SNTP, DNS,
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
Console port: RJ-45
SFP+ module slots quantity: 2
Logistics data
Master (outer) case height: 133 mm
Harmonized System (HS) code: 85176990
Master (outer) case width: 590 mm
Country of origin: China
Products per master (outer) case: 1 pc(s)
Master (outer) case length: 390 mm
Master (outer) case gross weight: 5.3 kg
Data transmission
Packet buffer memory: 1.5 MB
MAC address table: 16000 entries
Switching capacity: 128 Gbit/s
Forwarding rate: 95.23 Mpps
Store-and-forward: Yes
Static route: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
