Features Cable types supported: Cat5, Cat5e Type: Transmitter & receiver Maximum transfer distance: 100 m Plug and Play: Yes On Screen Display (OSD): Yes Material: Metal Maximum analog resolution: 1920 x 1200 pixels KVM port selection: Hotkeys, Push-buttons Connectivity technology: Wired Product colour: Black LED indicators: Yes
Operational conditions Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -5 - 65 °C Storage relative humidity (H-H): 5 - 95% Operating relative humidity (H-H): 5 - 95%
Weight & dimensions Transmitter depth: 6.5 cm Receiver height: 2.6 cm Transmitter height: 2.6 cm Receiver weight: 586 g Transmitter width: 13.1 cm Transmitter weight: 586 g Receiver depth: 6.5 cm Receiver width: 13.1 cm
Packaging data Package weight: 1.69 kg Package depth: 176 mm Package height: 139 mm Package width: 204 mm
Ports & interfaces USB port type: USB Type-B USB 2.0 ports quantity: 2
Other features Firmware upgradeable: Yes Compliance certificates: CE, Federal Communications Commission (FCC), UKCA, WEEE
Logistics data Country of origin: Taiwan Master (outer) case width: 440 mm Pallet gross length: 94 cm Pallet gross height: 11.5 cm Master (outer) case length: 370 mm Master (outer) case height: 430 mm Master (outer) case gross weight: 21.3 kg Products per master (outer) case: 12 pc(s) Pallet gross width: 135 cm
Transmitter RJ-45 ports quantity (transmitter): 1 Transmitter local keyboard/mouse port type: USB Transmitter local video port type: VGA Transmitter local video port: Yes Transmitter video port type: VGA
Receiver Receiver local keyboard/mouse port type: USB Receiver local video port type: VGA RJ-45 ports quantity (receiver): 1
