Design
International Protection (IP) code: IP55
Rack mounting: No
Stackable: No
LED indicators: Power, Link
Product colour: Black
Power
Power supply included: Yes
AC input frequency: 50/60 Hz
Power source: AC
Power consumption (max): 120 W
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -20 - 65 °C
Storage temperature (T-T): -40 - 75 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 280 mm
Weight: 8 kg
Depth: 200 mm
Height: 250 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at, IEEE 802.3z
Ethernet LAN data rates: 1000 Mbit/s
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-X, 1000BASE-T
Half duplex: Yes
Auto-negotiation: Yes
Flow control support: Yes
10G support: No
Full duplex: Yes
Auto MDI/MDI-X: Yes
Performance
Fanless: No
Mean time between failures (MTBF): 4000000 h
Packaging data
Package type: Box
Packaging content
Quick start guide: Yes
Manual: Yes
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC)
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity: 8
Power connector: DC-in jack
2.5G Ethernet (copper) ports quantity: 8
SFP+ module slots quantity: 2
Data transmission
Switching capacity: 20 Gbit/s
Packet buffer memory: 12 MB
MAC address table: 4000 entries
Jumbo frames: 9000
Jumbo frames support: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 115 W
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
