Design
International Protection (IP) code: IP55
Rack mounting: No
LED indicators: Power, Link
Stackable: No
Product colour: Black
Power
Power consumption (max): 200 W
Power source: AC
AC input frequency: 50/60 Hz
Power supply included: Yes
AC input voltage: 100 - 240 V
Security
Password protection: Yes
DHCP features: DHCP snooping
MAC address filtering: Yes
BPDU filtering/protection: Yes
Operational conditions
Storage temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -20 - 65 °C
Management features
Quality of Service (QoS) support: Yes
Switch type: Managed
Web-based management: Yes
System event log: Yes
Switch layer: L2
Traffic classification: Yes
Weight & dimensions
Weight: 8 kg
Width: 280 mm
Depth: 200 mm
Height: 250 mm
Network
VLAN support: Yes
Copper ethernet cabling technology: 10BASE-T, 1000BASE-X, 100BASE-TX, 1000BASE-T
Ethernet LAN data rates: 1000 Mbit/s
10G support: No
Half duplex: Yes
Port mirroring: Yes
Auto MDI/MDI-X: Yes
Full duplex: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.1s, IEEE 802.1ab, IEEE 802.1w, IEEE 802.1ag, IEEE 802.3at, IEEE 802.3ah, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.1x, IEEE 802.3bt, IEEE 802.3af, IEEE 802.1v, IEEE 802.1ad, IEEE 802.1D, IEEE 802.3z
Flow control support: Yes
Auto-negotiation: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Policy-based routing: Yes
Performance
Flash memory: 120 MB
Internal memory: 1 MB
Mean time between failures (MTBF): 4000000 h
Fanless: No
Packaging data
Package type: Box
Packaging content
Quick start guide: Yes
Manual: Yes
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC)
Protocols
IP Source Guard (IPSG): Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 8
SFP+ module slots quantity: 2
Data transmission
Switching capacity: 20 Gbit/s
Packet buffer memory: 12 MB
MAC address table: 8000 entries
Jumbo frames support: Yes
Forwarding rate: 14.88 Mpps
Jumbo frames: 9000
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 185 W
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
