Features
Product colour: Black
LED indicators: Activity, Link
Internal: No
Power
Input voltage: 5 V
Input current: 1 A
Operational conditions
Storage temperature (T-T): -10 - 55 °C
Operating temperature (T-T): 40 - 75 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 94 mm
Height: 25 mm
Depth: 70 mm
Weight: 420 g
Network
Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Maximum data transfer rate: 100 Mbit/s
Auto MDI/MDI-X: Yes
Ethernet interface type: Fast Ethernet
Ethernet LAN data rates: 10, 100
Converter output interface: 100Base-FX
Auto-negotiation: Yes
Duplex system: Full, Half
Flow control support: Yes
Link Loss Carry Forward (LLCF) supported: Yes
Converter input interface: 10Base-T, 100Base-TX
Store-and-forward: Yes
Link Loss Return (LLR) supported: Yes
Performance
Wavelength: 1310 nm
Fiber cable diameters supported (core/cladding): 50/125, 62.5/125 µm
Maximum transfer distance: 2000 m
Fiber mode structure: Multi-mode
Packaging data
Package depth: 125 mm
Package width: 235 mm
Package type: Box
Package height: 55 mm
Package weight: 494 g
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Certification: FCC, CE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Connectivity technology: Wired
Power over Ethernet (PoE) ports quantity: 1
Fiber optic connector: SC
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
