Features Internal: No Product colour: Black LED indicators: Yes
Power Input voltage: 5 V Input current: 1 A
Operational conditions Operating relative humidity (H-H): 5 - 90% Operating temperature (T-T): 0 - 50 °C Storage temperature (T-T): -20 - 70 °C
Weight & dimensions Width: 94 mm Height: 26 mm Depth: 71 mm Weight: 200 g
Network Auto-negotiation: Yes Ethernet interface type: Fast Ethernet Store-and-forward: Yes Ethernet LAN data rates: 100, 10 Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3u Converter input interface: 10Base-T, 100Base-TX Copper ethernet cabling technology: 10BASE-T, 100BASE-TX Maximum data transfer rate: 100 Mbit/s Auto MDI/MDI-X: Yes Fiber ethernet cabling technology: 100BASE-FX Converter output interface: 100Base-FX Flow control support: Yes Duplex system: Full
Performance Maximum transfer distance: 20000 m Fiber mode structure: Single-mode Fiber cable diameters supported (core/cladding): 62.5/125 µm, 50/125 Wavelength: 1310 nm Mean time between failures (MTBF): 100000 h
Packaging data Package width: 230 mm Package weight: 300 g Package height: 58 mm Package type: Blister Package depth: 150 mm
Packaging content AC adapter included: Yes Quick installation guide: Yes Certification: FCC, CE
Logistics data Harmonized System (HS) code: 85176990 Products per master (outer) case: 40 pc(s) Master (outer) case width: 440 mm Master (outer) case height: 305 mm Master (outer) case length: 420 mm Country of origin: China Master (outer) case gross weight: 32 kg
