Features Product colour: Black Internal: No LED indicators: Yes
Power Input voltage: 5 V Input current: 1 A
Operational conditions Storage temperature (T-T): -20 - 70 °C Operating relative humidity (H-H): 5 - 90% Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Width: 94 mm Height: 26 mm Weight: 200 g Depth: 71 mm
Network Ethernet interface type: Fast Ethernet Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3 Fiber ethernet cabling technology: 100BASE-FX Converter output interface: 100Base-FX Ethernet LAN data rates: 100, 10 Store-and-forward: Yes Auto MDI/MDI-X: Yes Auto-negotiation: Yes Maximum data transfer rate: 100 Mbit/s Converter input interface: 10Base-T, 100Base-TX Copper ethernet cabling technology: 100BASE-TX, 10BASE-T Flow control support: Yes
Performance Fiber mode structure: Single-mode Wavelength: 1310 nm Fiber cable diameters supported (core/cladding): 62.5/125 µm, 50/125 Mean time between failures (MTBF): 100000 h Maximum transfer distance: 40000 m
Packaging data Package depth: 150 mm Package width: 230 mm Package weight: 300 g Package type: Box Package height: 58 mm
Packaging content AC adapter included: Yes Quick installation guide: Yes Certification: FCC, CE
Logistics data Master (outer) case width: 440 mm Country of origin: China Master (outer) case height: 305 mm Products per master (outer) case: 40 pc(s) Harmonized System (HS) code: 85176990 Master (outer) case length: 420 mm Master (outer) case gross weight: 32 kg
