Features Product colour: Black LED indicators: Yes Internal: Yes
Power Input voltage: 5 V Input current: 1 A
Operational conditions Storage temperature (T-T): -20 - 70 °C Operating relative humidity (H-H): 5 - 90% Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Weight: 200 g Height: 26 mm Depth: 71 mm Width: 94 mm
Network Ethernet LAN data rates: 10, 100 Maximum data transfer rate: 100 Mbit/s Auto-negotiation: Yes Store-and-forward: Yes Converter output interface: 100Base-FX Duplex system: Full Fiber ethernet cabling technology: 100BASE-FX Flow control support: Yes Networking standards: IEEE 802.3, IEEE 802.3x, IEEE 802.3u Ethernet interface type: Fast Ethernet Converter input interface: 10Base-T, 100Base-TX Copper ethernet cabling technology: 10BASE-T Auto MDI/MDI-X: Yes
Performance Fiber mode structure: Single-mode Maximum transfer distance: 80000 m Fiber cable diameters supported (core/cladding): 50/125, 62.5/125 µm Mean time between failures (MTBF): 100000 h Wavelength: 1550 nm
Packaging data Package weight: 300 g Package depth: 150 mm Package height: 58 mm Package width: 230 mm Package type: Box
Packaging content AC adapter included: Yes Quick installation guide: Yes Certification: CE
Logistics data Country of origin: China Master (outer) case gross weight: 32 kg Master (outer) case length: 420 mm Master (outer) case height: 305 mm Products per master (outer) case: 40 pc(s) Master (outer) case width: 440 mm Harmonized System (HS) code: 85176990
