Features
Product colour: Black
LED indicators: Activity, Power, Link
Internal: No
Power
Input voltage: 5 - 12 V
Input current: 2 A
Operational conditions
Storage temperature (T-T): -10 - 55 °C
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 94 mm
Height: 25 mm
Depth: 70 mm
Weight: 420 g
Network
Cable types supported: Cat5, Cat5e
Link Loss Carry Forward (LLCF) supported: Yes
Duplex system: Full
Ethernet interface type: Gigabit Ethernet
Converter output interface: 1000Base-SX, 1000Base-LX
Flow control support: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Jumbo frames support: Yes
Link Loss Return (LLR) supported: Yes
Jumbo frames: 9000
Store-and-forward: Yes
Converter input interface: 10Base-T, 100Base-TX, 1000Base-T
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z, IEEE 802.3x
Maximum data transfer rate: 1000 Mbit/s
Performance
Maximum transfer distance: 550 m
Wavelength: 850 nm
Fiber mode structure: Multi-mode
Packaging data
Package width: 235 mm
Package weight: 530 g
Package depth: 125 mm
Package type: Box
Package height: 55 mm
Packaging content
Quick installation guide: Yes
AC adapter included: Yes
Certification: CE, FCC
Certificates
Compliance certificates: RoHS
Ports & interfaces
Fiber ports quantity: 1
Fiber optic connector: SC
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Connectivity technology: Wired
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
