Features
Product colour: Grey
LED indicators: Power, Link, Activity
Internal: No
Power
Input voltage: 100 - 240 V
Total Power over Ethernet (PoE) budget: 30 W
Power consumption (max): 40 W
Output voltage: 48 V
AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE): Yes
Input current: 1.6 A
Output current: 2 A
External power adapter: Yes
Operational conditions
Operating temperature (T-T): 10 - 60 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Depth: 94 mm
Height: 26 mm
Weight: 200 g
Width: 70 mm
Network
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Maximum data transfer rate: 1000 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3at, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
Auto MDI/MDI-X: Yes
Duplex system: Full, Half
Flow control support: Yes
Auto-negotiation: Yes
Jumbo frames: 9000
Jumbo frames support: Yes
Store-and-forward: Yes
Performance
Wavelength: 850 nm
Maximum transfer distance: 500 m
Fiber mode structure: Multi-mode
Packaging data
Package width: 230 mm
Package depth: 150 mm
Package height: 60 mm
Package weight: 650 g
Packaging content
AC adapter included: Yes
User guide: Yes
Ports & interfaces
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: SC
Logistics data
Country of origin: China
Products per master (outer) case: 20 pc(s)
Master (outer) case gross weight: 13.8 kg
Master (outer) cases per pallet (air): 23 pc(s)
Master (outer) case width: 480 mm
Pallet height (air): 176.9 cm
Pallet gross length: 80 cm
Pallet gross width: 120 cm
Master (outer) case height: 325 mm
Master (outer) case length: 305 mm
