Features
Product colour: Grey
Internal: No
LED indicators: Activity, Link, Power
Power
Output voltage: 48 V
Power consumption (max): 40 W
Input voltage: 100 - 240 V
Total Power over Ethernet (PoE) budget: 30 W
AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE): Yes
External power adapter: Yes
Input current: 1.6 A
Output current: 2 A
Operational conditions
Operating temperature (T-T): 10 - 60 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Depth: 94 mm
Width: 70 mm
Height: 26 mm
Weight: 200 g
Network
Store-and-forward: Yes
Flow control support: Yes
Duplex system: Full, Half
Jumbo frames: 9000
Jumbo frames support: Yes
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3u, IEEE 802.3z, IEEE 802.3at, IEEE 802.3af
Auto-negotiation: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Maximum data transfer rate: 1000 Mbit/s
Performance
Maximum transfer distance: 20000 m
Wavelength: 1310 nm
Fiber mode structure: Single-mode
Packaging data
Package depth: 150 mm
Package weight: 650 g
Package width: 230 mm
Package height: 60 mm
Packaging content
User guide: Yes
AC adapter included: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
Fiber ports quantity: 1
Fiber optic connector: SC
Logistics data
Master (outer) case length: 305 mm
Master (outer) case gross weight: 13.8 kg
Master (outer) cases per pallet (air): 23 pc(s)
Pallet gross length: 80 cm
Country of origin: China
Pallet gross width: 120 cm
Master (outer) case width: 480 mm
Pallet height (air): 176.9 cm
Products per master (outer) case: 20 pc(s)
Master (outer) case height: 325 mm
