Features
Product colour: Black
Internal: No
LED indicators: Yes
Power
Input voltage: 5 V
Input current: 2 A
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 75 °C
Weight & dimensions
Weight: 200 g
Height: 71 mm
Width: 94 mm
Depth: 26 mm
Network
Networking standards: IEEE 802.3u, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x
Maximum data transfer rate: 1000 Mbit/s
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Converter input interface: 1000Base-T, 100Base-TX, 10Base-T
Auto MDI/MDI-X: Yes
Ethernet interface type: Gigabit Ethernet
Jumbo frames support: Yes
Duplex system: Full
Link Loss Return (LLR) supported: Yes
Flow control support: Yes
Converter output interface: 1000Base-LX, 1000Base-SX
Fiber ethernet cabling technology: 1000BASE‑LX, 1000BASE‑SX
Jumbo frames: 9000
Store-and-forward: Yes
Link Loss Carry Forward (LLCF) supported: Yes
Cable types supported: Cat5, Cat5e
Auto-negotiation: Yes
Performance
Wavelength: 1310 nm
Maximum transfer distance: 20000 m
Fiber mode structure: Single-mode
Packaging data
Package height: 235 mm
Package width: 120 mm
Package weight: 360 g
Package type: Box
Package depth: 55 mm
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Ports & interfaces
DC-in jack: Yes
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: SC
Logistics data
Country of origin: China
Products per master (outer) case: 36 pc(s)
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 13 kg
Master (outer) case length: 390 mm
Master (outer) case height: 480 mm
Master (outer) case width: 360 mm
