Features
Web-based management: Yes
Product colour: Black
LED indicators: Link, Power, FDX, Activity
Power
Output voltage: 5 V
Output current: 2 A
Input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Depth: 156 mm
Width: 127 mm
Height: 32 mm
Weight: 720 g
Network
Duplex system: Full, Half
Jumbo frames: 9000
Store-and-forward: Yes
Ethernet interface type: Fast Ethernet
Flow control support: Yes
Jumbo frames support: Yes
Converter output interface: 100Base-FX
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 100BASE-FX
Converter input interface: 100Base-TX, 10Base-T
VLAN support: Yes
Ethernet LAN data rates: 10, 100
Networking standards: IEEE 802.3x, IEEE 802.3ah, IEEE 802.3, IEEE 802.3u
Maximum data transfer rate: 100 Mbit/s
Performance
Maximum transfer distance: 2000 m
Wavelength: 1310 nm
Packaging data
Package height: 62 mm
Package depth: 275 mm
Package width: 185 mm
Package type: Box
Package weight: 880 g
Certification: FCC, CE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Fiber ports quantity: 1
Fiber optic connector: ST, LC, SC
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Logistics data
Master (outer) case width: 360 mm
Master (outer) case gross weight: 17.5 kg
Master (outer) case length: 480 mm
Master (outer) case height: 390 mm
Harmonized System (HS) code: 85176990
Products per master (outer) case: 17 pc(s)
Country of origin: China
