Features
Product colour: Grey
Internal: No
Power
Input voltage: 5 V
External power adapter: Yes
Input current: 1 A
Power consumption (typical): 1.5 W
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Height: 26.2 mm
Width: 70.3 mm
Depth: 94 mm
Network
Converter input interface: 10Base-T, 100Base-TX
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ah, IEEE 802.3, IEEE 802.3u
Jumbo frames support: Yes
Flow control support: Yes
Maximum data transfer rate: 100 Mbit/s
Converter output interface: 100Base-LX
Ethernet LAN data rates: 100, 10
Performance
Fiber cable diameters supported (core/cladding): 9/125 µm, 10/125 µm, 3/125, 8.7/125
Fiber mode structure: Single-mode
Maximum transfer distance: 20000 m
Packaging data
Package width: 160 mm
Package weight: 460 g
Package height: 60 mm
Package depth: 220 mm
Packaging content
Manual: Yes
Ports & interfaces
Connectivity technology: Wired
Fiber optic connector: SC
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Fiber ports quantity: 1
Logistics data
Country of origin: Taiwan
