Features
Web-based management: Yes
Product colour: Black
LED indicators: Activity, Power, Link, FDX
Internal: No
Power
Input voltage: 100 - 240 V
Output voltage: 5 V
Output current: 2 A
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 127 mm
Height: 32 mm
Weight: 720 g
Depth: 156 mm
Network
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Duplex system: Half, Full
VLAN support: Yes
Maximum data transfer rate: 1000 Mbit/s
Networking standards: IEEE 802.3ah, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z
Fiber ethernet cabling technology: 1000BASE-X
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Flow control support: Yes
Jumbo frames: 9000
Store-and-forward: Yes
Jumbo frames support: Yes
Ethernet interface type: Gigabit Ethernet
Performance
Fiber mode structure: Single-mode
Maximum transfer distance: 20000 m
Wavelength: 1310 nm
Mean time between failures (MTBF): 30000 h
Packaging data
Package depth: 275 mm
Package height: 62 mm
Package type: Box
Package weight: 880 g
Package width: 185 mm
Certification: CE, FCC
Certificates
Compliance certificates: RoHS
Ports & interfaces
Fiber optic connector: FC, SC, ST
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Connectivity technology: Wired
Logistics data
Products per master (outer) case: 17 pc(s)
Master (outer) case gross weight: 17.5 kg
Harmonized System (HS) code: 85176990
Country of origin: China
Master (outer) case width: 360 mm
Master (outer) case height: 390 mm
Master (outer) case length: 480 mm
