Features
Plug and Play: Yes
Internal: No
LED indicators: Yes
Product colour: Black
Power
Output voltage: 5 V
External power adapter: Yes
Output current: 2 A
Power consumption (typical): 6.7 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 85 °C
Weight & dimensions
Width: 71 mm
Height: 26 mm
Depth: 94 mm
Weight: 300 g
Network
Ethernet interface type: 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Gigabit Ethernet
Converter input interface: 10GBase-T
Maximum data transfer rate: 10000 Mbit/s
Networking standards: IEEE 802.3u, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3az, IEEE 802.3an
Ethernet LAN data rates: 10000 Mbit/s, 1000 Mbit/s, 5000 Mbit/s, 2500
Packaging data
Package width: 118 mm
Package weight: 350 g
Package height: 86 mm
Package type: Box
Package depth: 78 mm
Packaging content
User guide: Yes
AC adapter included: Yes
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE, UKCA
Ports & interfaces
Fiber optic connector: SFP+
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
DC-in jack: Yes
Connectivity technology: Wired
Logistics data
Master (outer) case height: 500 mm
Products per master (outer) case: 36 pc(s)
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Master (outer) case width: 250 mm
Pallet height (air): 165 cm
Master (outer) case length: 280 mm
Harmonized System (HS) code: 8517620090
Master (outer) case gross weight: 13.2 kg
Master (outer) cases per pallet (air): 27 pc(s)
Country of origin: China
Sustainability
Sustainability compliance: Yes
