Features Product colour: Black Housing material: Aluminium Internal: No LED indicators: Power, Link, Activity
Power Input voltage: 12 - 60 V Power consumption (typical): 1.44 W
Operational conditions Storage temperature (T-T): -40 - 75 °C Operating temperature (T-T): -40 - 75 °C Operating relative humidity (H-H): 5 - 95%
Weight & dimensions Height: 36 mm Width: 59 mm Depth: 49 mm Weight: 90 g
Network Duplex system: Full, Half Flow control support: Yes Converter input interface: 10Base-T, 100Base-TX Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x Auto-negotiation: Yes Store-and-forward: Yes Converter output interface: 100Base-X Auto MDI/MDI-X: Yes Maximum data transfer rate: 100 Mbit/s
Packaging data Package weight: 260 g Package depth: 105 mm Package type: Box Package height: 65 mm Package width: 160 mm
Packaging content Quick installation guide: Yes Certification: FCC Part 15 Subpart B Class A
CE EN 55022 Class A
FCC Part 15 Subpart B Class A,
CE EN 55022 Class A
EN61000-4-2 (ESD) Level 3
EN61000-4-3 (RS) Level 2
EN61000-4-4 (EFT) Level 2
EN61000-4-5 (Surge) Level 2
EN61000-4-6 (CS) Level 2
EN 61000-4-8 (PFMF) Level 1
UL508 (Pending)
EN 50121-4 (Pending)
IEC 60068-2-27
IEC 60068-2-32
IEC 60068-2-6
