Features
DIN rail mounting: Yes
Internal: No
LED indicators: Power, Link, Activity
Power
Total Power over Ethernet (PoE) budget: 30 W
Input voltage: 48 - 56 V
Power over Ethernet (PoE): Yes
Power consumption (typical): 2 W
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 75 °C
Weight & dimensions
Height: 103.5 mm
Depth: 81.5 mm
Width: 32 mm
Weight: 135 g
Network
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Jumbo frames: 9000
Ethernet interface type: Gigabit Ethernet
Jumbo frames support: Yes
Flow control support: Yes
Networking standards: IEEE 802.3u, IEEE 802.3at, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3z
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Maximum data transfer rate: 1000 Mbit/s
Performance
Mean time between failures (MTBF): 500000 h
Packaging data
Package height: 215 mm
Package weight: 350 g
Package width: 165 mm
Package depth: 65 mm
Packaging content
Manual: Yes
Certification: CE, FCC, VCCI, FCC Part 15 Subpart B Class A, CE EN 55022 Class A
Certificates
Safety: IEC EN60950-1
Ports & interfaces
Power over Ethernet (PoE) ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Fiber optic connector: SFP
Fiber ports quantity: 1
Connectivity technology: Wired
Logistics data
Harmonized System (HS) code: 85176990
Products per master (outer) case: 16 pc(s)
Master (outer) case height: 560 mm
Master (outer) case length: 240 mm
Master (outer) case gross weight: 6.6 kg
Master (outer) case width: 350 mm
Country of origin: Taiwan
