Features
Housing material: Aluminium
Product colour: Black
LED indicators: Status, Power, Activity, Link
International Protection (IP) code: IP30
Internal: No
DIN rail mounting: Yes
Power
Power consumption (max): 7.68 W
Input voltage: 12 - 48 V
Output current (48V): 0.16 A
Operational conditions
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Height: 135 mm
Depth: 110 mm
Weight: 800 g
Width: 50 mm
Network
Duplex system: Half, Full
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3u
Converter output interface: 1000Base-LX, 1000Base-SX
Maximum data transfer rate: 1000 Mbit/s
Packet forwarding rate (1 Gbps): 1488100 pps
Auto-negotiation: Yes
Converter input interface: 1000Base-TX, 10Base-T, 100Base-TX
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Auto MDI/MDI-X: Yes
Ethernet interface type: Gigabit Ethernet
Performance
Mean time between failures (MTBF): 665760 h
Packaging data
Package depth: 92 mm
Package weight: 1 kg
Package height: 236 mm
Package width: 198 mm
Package type: Box
Packaging content
Quick installation guide: Yes
Certification: - ISO9001
- FCC Part 15, Class A
- EN61000-6-3
- EN55022
- EN61000-3-2
- EN61000-3-3
- EN61000-6-2
- EN61000-4-2
- EN61000-4-3
- EN61000-4-4
- EN61000-4-5
- EN61000-4-6
- EN61000-4-8
- IEC60068-2-6 Fc
- IEC60068-2-27 Ea
- FED STD 101C Method 5007.1
Certificates
Safety: UL508
Ports & interfaces
Fiber optic connector: SFP
Connectivity technology: Wired
Fiber ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Logistics data
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
