Features
Internal: No
Product colour: Black
LED indicators: Link, Power, Activity
Power
Input voltage: 5 V
Input current: 2 A
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Depth: 70 mm
Height: 25 mm
Width: 94 mm
Weight: 420 g
Network
Jumbo frames: 9000
Auto-negotiation: Yes
Jumbo frames support: Yes
Converter output interface: 1000Base-SX, 1000Base-LX
Store-and-forward: Yes
Link Loss Return (LLR) supported: Yes
Flow control support: Yes
Converter input interface: 1000Base-T, 10Base-T, 100Base-TX
Cable types supported: Cat5, Cat5e
Link Loss Carry Forward (LLCF) supported: Yes
Ethernet interface type: Gigabit Ethernet
Maximum data transfer rate: 1000 Mbit/s
Auto MDI/MDI-X: Yes
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Performance
Maximum transfer distance: 100 m
Fiber mode structure: Multi-mode
Packaging data
Package height: 55 mm
Package type: Box
Package width: 235 mm
Package weight: 490 g
Package depth: 125 mm
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Certification: CE, FCC
Certificates
Compliance certificates: RoHS
Ports & interfaces
Fiber optic connector: SFP
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
