Features
Web-based management: No
LED indicators: PoE, Power, LAN
Product colour: Black
Internal: No
Power
AC input frequency: 50 - 60 Hz
Output voltage: 54.5 V
Power consumption (max): 72.4 W
Total Power over Ethernet (PoE) budget: 60 W
Power consumption (typical): 0.97 W
Output current: 1.32 A
Input voltage: 100 - 240 V
Input current: 1.8 A
Power over Ethernet (PoE): Yes
Operational conditions
Storage temperature (T-T): -40 - 80 °C
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
Depth: 70 mm
Width: 93.5 mm
Weight: 320 g
Height: 26 mm
Network
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Auto MDI/MDI-X: Yes
Maximum data transfer rate: 1000 Mbit/s
Jumbo frames: 9000
Copper ethernet cabling technology: 1000BASE-X, 100BASE-TX, 1000BASE-T
Auto-negotiation: Yes
Flow control support: Yes
Jumbo frames support: Yes
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Networking standards: IEEE 802.3af, IEEE 802.3bt, IEEE 802.3x, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z
Performance
Fiber mode structure: Multi-mode, Single-mode
Packaging data
Package weight: 715 g
Package width: 240 mm
Package depth: 186 mm
Package height: 84 mm
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), UKCA, RCM
Ports & interfaces
Fiber ports quantity: 1
Power over Ethernet plus (PoE+) ports quantity: 1
Fiber optic connector: SFP
Connectivity technology: Wired
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Logistics data
Master (outer) case length: 264 mm
Pallet gross width: 120 cm
Harmonized System (HS) code: 851762
Pallet gross length: 100 cm
Country of origin: China
Products per master (outer) case: 10 pc(s)
Master (outer) case width: 450 mm
Master (outer) case gross weight: 8.24 kg
Master (outer) cases per pallet (air): 32 pc(s)
Master (outer) case height: 390 mm
Pallet height (air): 171 cm
