Features
Internal: No
Product colour: Black
LED indicators: PoE, LAN, Power
Power
Output voltage: 55 V
Total Power over Ethernet (PoE) budget: 90 W
AC input frequency: 50 - 60 Hz
Power consumption (max): 105.4 W
Input voltage: 100 - 240 V
Output current: 2.3 A
Power consumption (typical): 2.42 W
Input current: 2 A
Operational conditions
Operating temperature (T-T): 0 - 55 °C
Storage temperature (T-T): -40 - 80 °C
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Width: 93.5 mm
Weight: 351 g
Depth: 70 mm
Height: 26 mm
Network
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Maximum data transfer rate: 1000 Mbit/s
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3u, IEEE 802.3x, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bt, IEEE 802.3af
Jumbo frames: 9000
Jumbo frames support: Yes
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Copper ethernet cabling technology: 10BASE-T, 1000BASE-X, 100BASE-TX, 1000BASE-T
Auto-negotiation: Yes
Flow control support: Yes
Performance
Fiber mode structure: Single-mode, Multi-mode
Packaging data
Package width: 240 mm
Package depth: 186 mm
Package height: 84 mm
Package weight: 937 g
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Certificates
Compliance certificates: UKCA, Low Voltage Directive (LVD), RoHS, CE, Federal Communications Commission (FCC), RCM
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Connectivity technology: Wired
Fiber ports quantity: 1
Fiber optic connector: SFP
Logistics data
Country of origin: China
Master (outer) case width: 450 mm
Pallet height (air): 171 cm
Pallet gross length: 100 cm
Products per master (outer) case: 10 pc(s)
Master (outer) cases per pallet (air): 32 pc(s)
Master (outer) case length: 264 mm
Master (outer) case gross weight: 8.62 kg
Pallet gross width: 120 cm
Harmonized System (HS) code: 851762
Master (outer) case height: 390 mm
