Features
Web-based management: Yes
Internal: No
Product colour: Black
LED indicators: Activity, Power, Link, FDX
Power
Output voltage: 5 V
Input voltage: 90 - 264 V
Output current: 2 A
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -10 - 60 °C
Weight & dimensions
Depth: 71 mm
Height: 26 mm
Weight: 220 g
Width: 94 mm
Network
Fiber ethernet cabling technology: 1000BASE‑SX, 1000BASE‑LX
VLAN support: Yes
Store-and-forward: Yes
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-T
Jumbo frames: 9000
Jumbo frames support: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3z, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Duplex system: Full, Half
Flow control support: Yes
Auto MDI/MDI-X: Yes
Performance
Mean time between failures (MTBF): 30000 h
Packaging data
Package weight: 430 g
Package height: 235 mm
Package width: 120 mm
Package depth: 55 mm
Packaging content
Manual: Yes
Certification: CE, FCC
Certificates
Compliance certificates: RoHS
Ports & interfaces
Power over Ethernet plus (PoE+) ports quantity: 1
Fiber optic connector: SFP
Fiber ports quantity: 1
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Logistics data
Harmonized System (HS) code: 85176990
