Features
Internal: No
Product colour: Grey
LED indicators: Link, Power
Power
Input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Total Power over Ethernet (PoE) budget: 30 W
Power consumption (max): 33 W
Power over Ethernet (PoE): Yes
External power adapter: Yes
Input current: 2 A
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Width: 94 mm
Height: 26 mm
Weight: 182 g
Depth: 71 mm
Network
Maximum data transfer rate: 1000 Mbit/s
Ethernet interface type: Gigabit Ethernet, Fast Ethernet
Converter input interface: 100Base-T, 1000Base-T, 10Base-T
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3x, IEEE 802.3u, IEEE 802.3af, IEEE 802.3z
Store-and-forward: Yes
Auto MDI/MDI-X: Yes
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Converter output interface: 1000Base-X
Auto-negotiation: Yes
Jumbo frames support: Yes
Jumbo frames: 9000
Flow control support: Yes
Duplex system: Full, Half
Performance
Mean time between failures (MTBF): 400000 h
Packaging data
Package weight: 850 g
Package type: Box
Package height: 72 mm
Package width: 202 mm
Package depth: 145 mm
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, UKCA
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
DC-in jack: Yes
Fiber ports quantity: 1
Fiber optic connector: SFP
Logistics data
Harmonized System (HS) code: 8517620000
Pallet gross length: 80 cm
Master (outer) case length: 310 mm
Master (outer) case width: 425 mm
Pallet gross height: 170.4 cm
Pallet gross width: 120 cm
Country of origin: China
Master (outer) case gross weight: 17.7 kg
Master (outer) case height: 390 mm
Products per master (outer) case: 20 pc(s)
