Features
Product colour: Grey
LED indicators: Activity, Link, Power
Internal: No
Power
Output current: 2 A
Input voltage: 110 - 240 V
Power consumption (max): 5 W
Output voltage: 5 V
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 71 mm
Weight: 300 g
Height: 26 mm
Depth: 94 mm
Network
Maximum data transfer rate: 1000 Mbit/s
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3u
Jumbo frames: 9000
Jumbo frames support: Yes
Auto-negotiation: Yes
Auto MDI/MDI-X: Yes
Converter input interface: 10Base-T, 1000Base-T, 100Base-TX
VLAN support: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Converter output interface: 1000Base-X
Store-and-forward: Yes
Ethernet interface type: Gigabit Ethernet
Duplex system: Half, Full
Flow control support: Yes
Performance
Mean time between failures (MTBF): 30000 h
Packaging data
Package type: Box
Package height: 55 mm
Package weight: 380 g
Package width: 120 mm
Package depth: 235 mm
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Ports & interfaces
Connectivity technology: Wired
DC-in jack: Yes
Fiber ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Fiber optic connector: SFP
Logistics data
Country of origin: China
Master (outer) case length: 480 mm
Products per master (outer) case: 36 pc(s)
Harmonized System (HS) code: 85176990
Master (outer) case width: 360 mm
Master (outer) case height: 390 mm
Master (outer) case gross weight: 1.2 kg
