Features
Web-based management: Yes
Internal: No
Product colour: Black
LED indicators: Activity, Link, Power, FDX
Hot-swap: Yes
Power
Input voltage: 100 - 240 V
Output voltage: 5 V
Output current: 2 A
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Weight: 700 g
Height: 32 mm
Depth: 156 mm
Width: 127 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab
Jumbo frames: 9000
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Jumbo frames support: Yes
Maximum data transfer rate: 1000 Mbit/s
Ethernet interface type: Gigabit Ethernet
Link Loss Return (LLR) supported: Yes
Store-and-forward: Yes
Link Loss Carry Forward (LLCF) supported: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Duplex system: Half, Full
Flow control support: Yes
VLAN support: Yes
Performance
Mean time between failures (MTBF): 30000 h
Packaging data
Package weight: 860 g
Package width: 185 mm
Package depth: 275 mm
Package height: 62 mm
Packaging content
Manual: Yes
Certification: CE, FCC
Certificates
Compliance certificates: RoHS
Ports & interfaces
Connectivity technology: Wired
Fiber ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Fiber optic connector: SFP
Logistics data
Country of origin: China
Master (outer) case width: 360 mm
Master (outer) case gross weight: 17.5 kg
Master (outer) case length: 480 mm
Products per master (outer) case: 17 pc(s)
Master (outer) case height: 390 mm
Harmonized System (HS) code: 85176990
