Features Product colour: Black Internal: No LED indicators: Link, Power, Activity Housing material: Aluminium
Power Input voltage: 12 - 60 V Power consumption (typical): 1.44 W
Operational conditions Storage temperature (T-T): -40 - 75 °C Operating relative humidity (H-H): 5 - 95% Operating temperature (T-T): -40 - 75 °C
Weight & dimensions Height: 36 mm Weight: 90 g Width: 59 mm Depth: 49 mm
Network Duplex system: Half, Full Flow control support: Yes Converter input interface: 10Base-T, 100Base-TX Auto-negotiation: Yes Converter output interface: 100Base-FX Maximum data transfer rate: 100 Mbit/s Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3 Auto MDI/MDI-X: Yes
Performance Maximum transfer distance: 2000 m Fiber mode structure: Multi-mode
Packaging data Package type: Box Package weight: 260 g Package depth: 105 mm Package height: 65 mm Package width: 160 mm
Packaging content Quick installation guide: Yes Certification: FCC Part 15 Subpart B Class A
CE EN 55022 Class A
FCC Part 15 Subpart B Class A,
CE EN 55022 Class A
EN61000-4-2 (ESD) Level 3
EN61000-4-3 (RS) Level 2
EN61000-4-4 (EFT) Level 2
EN61000-4-5 (Surge) Level 2
EN61000-4-6 (CS) Level 2
EN 61000-4-8 (PFMF) Level 1
UL508 (Pending)
EN 50121-4 (Pending)
IEC 60068-2-27
IEC 60068-2-32
IEC 60068-2-6
Certificates Compliance certificates: RoHS
Ports & interfaces Fiber optic connector: ST Connectivity technology: Wired Ethernet LAN (RJ-45) ports: 1 Fiber ports quantity: 1
Logistics data Harmonized System (HS) code: 85176990 Country of origin: Taiwan
