Features
Product colour: Black
Internal: No
LED indicators: Link, Power
Power
Power consumption (typical): 5 W
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Depth: 94 mm
Height: 26 mm
Weight: 200 g
Width: 71 mm
Network
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Ethernet interface type: Gigabit Ethernet, Fast Ethernet
Link Loss Carry Forward (LLCF) supported: Yes
Duplex system: Half, Full
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3u
Jumbo frames: 9000
Converter input interface: 1000Base-LX, 1000Base-SX
Maximum data transfer rate: 1000 Mbit/s
Link Loss Return (LLR) supported: Yes
Flow control support: Yes
Jumbo frames support: Yes
Link Fault Pass-through (LFP): Yes
Performance
Maximum transfer distance: 20000 m
Fiber mode structure: Single-mode
Wavelength: 1310 nm
Packaging data
Package height: 55 mm
Package weight: 840 g
Package depth: 120 mm
Package type: Box
Package width: 235 mm
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Certificates
Compliance certificates: CE
Ports & interfaces
Fiber optic connector: ST
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
Logistics data
Products per master (outer) case: 36 pc(s)
Pallet height (air): 158.4 cm
Master (outer) cases per pallet (air): 16 pc(s)
Master (outer) case height: 480 mm
Master (outer) case gross weight: 31.2 kg
Country of origin: China
Master (outer) case width: 360 mm
Pallet gross length: 80 cm
Pallet gross width: 120 cm
Master (outer) case length: 390 mm
Sustainability
Sustainability compliance: Yes
