Design
Product colour: Grey
LED indicators: System, Status, Power, Alarm
Safety: UL,CB
Reset button: Yes
DIN rail mounting: Yes
Power
Power consumption (max): 239.2 W
DC input voltage: 48 - 57 V
Security
DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping
Root protection: Yes
BPDU filtering/protection: Yes
Access Control List (ACL): Yes
Loop protection: Yes
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 36.03 BTU/h
Management features
Web-based management: Yes
Switch layer: L3
System event log: Yes
Switch type: Managed
Weight & dimensions
Depth: 130 mm
Height: 135 mm
Width: 62 mm
Weight: 700 g
Network
Networking standards: IEEE 802.3ah, IEEE 802.1Q, IEEE 802.1x, IEEE 802.1w, IEEE 802.3ac, IEEE 802.1D, IEEE 802.1ab, IEEE 802.3az, IEEE 802.1ag, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
VLAN support: Yes
10G support: No
Spanning tree protocol: Yes
Broadcast storm control: Yes
Link aggregation: Yes
Ethernet Ring Protection Switching (ERPS): Yes
Port mirroring: Yes
Performance
Internal memory: 128 MB
Firmware upgradeable: Yes
Flash memory: 32 MB
Remarking priority: Y
sFlow: Yes
Mean time between failures (MTBF): 476206 h
Packaging data
Package depth: 207 mm
Package weight: 900 g
Package height: 85 mm
Package type: Box
Package width: 255 mm
Resource CD: Yes
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45)
Protocols
Supported network protocols: IPv4/IPv6
Management protocols: SNMP, Web, Telnet, SSH
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
SFP module slots quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Console port: RJ-45
Logistics data
Country of origin: Taiwan
Products per master (outer) case: 10 pc(s)
Harmonized System (HS) code: 85176990
Master (outer) case length: 445 mm
Master (outer) case height: 220 mm
Master (outer) case width: 520 mm
Master (outer) case gross weight: 2.4 kg
Data transmission
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 9216
Static route: Yes
Switching capacity: 24 Gbit/s
Forwarding rate: 17.856 Mpps
Packet buffer memory: 0.5 MB
MAC address table: 8000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
