Design
Safety: UL, CB
Product colour: Grey
DIN rail mounting: Yes
Reset button: Yes
International Protection (IP) code: IP30
LED indicators: Status, Alarm, Power, Ring, System
Power
DC input voltage: 48 - 57 V
Redundant power supply (RPS) support: Yes
Power consumption (max): 239.2 W
Power protection features: Short circuit
Security
DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping
IGMP snooping: Yes
SSH/SSL support: Yes
Root protection: Yes
BPDU tunneling: Yes
Access Control List (ACL): Yes
Loop protection: Yes
Operational conditions
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 10 - 90%
Heat dissipation: 816.18 BTU/h
Management features
System event log: Yes
Switch layer: L3
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Height: 135 mm
Width: 62 mm
Depth: 130 mm
Weight: 700 g
Network
Virtual LAN features: Voice VLAN, IP subnet–based VLAN, MAC address-based VLAN, Private VLAN, Protocol-based VLAN
Port mirroring: Yes
VLAN support: Yes
Cable length detection: Yes
Ethernet Ring Protection Switching (ERPS): Yes
10G support: No
Link aggregation: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-T
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3ah, IEEE 802.1w, IEEE 802.3ac, IEEE 802.1ag, IEEE 802.1Q, IEEE 802.3af, IEEE 802.3az, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1x, IEEE 802.1ab, IEEE 802.1D
Performance
Telnet: Yes
sFlow: Yes
Internal memory: 128 MB
Firmware upgradeable: Yes
Flash memory: 32 MB
Mean time between failures (MTBF): 476206 h
Packaging data
Package depth: 207 mm
Package weight: 900 g
Package width: 255 mm
Resource CD: Yes
Package height: 85 mm
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45)
Manual: Yes
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Management protocols: SNMP, Web, Telnet, SSH
Supported network protocols: IPv4/IPv6
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 16
Console port: RJ-45
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 4
Logistics data
Products per master (outer) case: 10 pc(s)
Harmonized System (HS) code: 85176990
Master (outer) case length: 445 mm
Master (outer) case width: 520 mm
Master (outer) case height: 220 mm
Master (outer) case gross weight: 2.4 kg
Country of origin: Taiwan
Data transmission
Switching capacity: 24 Gbit/s
Packet buffer memory: 0.5 MB
Forwarding rate: 17.856 Mpps
MAC address table: 8000 entries
Static route: Yes
Jumbo frames support: Yes
Jumbo frames: 9216
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet plus (PoE+) ports quantity: 8
Total Power over Ethernet (PoE) budget: 240 W
Power over Ethernet (PoE): Yes
