Design
LED indicators: Link, PoE, System, Activity, Speed
Safety: CB IEC-60950, UL 60950-1, 2nd Edition, 2014-10-14, CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-10
Rack mounting: Yes
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 20.71 W
Security
SSH/SSL support: Yes
Access Control List (ACL): Yes
BPDU filtering/protection: Yes
Loop protection: Yes
Security algorithms: 802.1x RADIUS
DHCP features: DHCP server, DHCP client, DHCP relay, DHCP snooping
IGMP snooping: Yes
Operational conditions
Storage relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Management features
Switch layer: L3
Switch type: Managed
Web-based management: Yes
System event log: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Height: 44 mm
Weight: 3.5 kg
Width: 442 mm
Depth: 211 mm
Network
Flow control support: Yes
Broadcast storm control: Yes
Networking standards: IEEE 802.1x, IEEE 802.3u, IEEE 802.3af, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.3at
Virtual LAN features: Private VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN
Spanning tree protocol: Yes
Link aggregation: Yes
10G support: No
Cable length detection: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
VLAN support: Yes
Performance
Firmware upgradeable: Yes
Telnet: Yes
sFlow: Yes
Buffer size: 512 KB
Internal memory: 128 MB
Flash memory: 32 MB
Mean time between failures (MTBF): 211272 h
Packaging data
Package width: 300 mm
Package depth: 520 mm
Package weight: 3.9 kg
Package type: Blister
Package height: 90 mm
Resource CD: Yes
Packaging content
Cables included: AC, LAN (RJ-45)
Quick start guide: Yes
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Supported network protocols: IPv4/IPv6
Ports & interfaces
Console port: RJ-45
Combo SFP ports quantity: 2
Gigabit Ethernet (copper) ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
Logistics data
Country of origin: Taiwan
Master (outer) case height: 324 mm
Harmonized System (HS) code: 85176990
Products per master (outer) case: 5 pc(s)
Master (outer) case gross weight: 20.7 kg
Master (outer) case width: 482 mm
Master (outer) case length: 540 mm
Data transmission
Forwarding rate: 38.7 Mpps
Store-and-forward: Yes
Static route: Yes
Jumbo frames: 9600
Switching capacity: 52 Gbit/s
Jumbo frames support: Yes
MAC address table: 8000 entries
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 24
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
Optical fiber
Fiber ethernet cabling technology: 1000BASE-X
