Design
Rack mounting: Yes
Reset button: Yes
LED indicators: Link, PoE, Activity, Speed
Safety: UL 60950-1, 2nd Edition, 2014-10-14, CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-10
Product colour: Black
Power
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 18.29 W
Security
Access Control List (ACL): Yes
IGMP snooping: Yes
Loop protection: Yes
DHCP features: DHCP snooping, DHCP client, DHCP server
Static port security: Yes
Security algorithms: 802.1x RADIUS
BPDU filtering/protection: Yes
Operational conditions
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -20 - 70 °C
Management features
System event log: Yes
Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes
Weight & dimensions
Depth: 211 mm
Weight: 3.1 kg
Height: 44 mm
Width: 442 mm
Network
Virtual LAN features: MAC address-based VLAN, Port-based VLAN, Tagged VLAN
MAC address auto-aging supported: Yes
Port mirroring: Yes
MAC address auto-learning supported: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Number of VLANs: 256
Cable length detection: Yes
Flow control support: Yes
VLAN support: Yes
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-T
Networking standards: IEEE 802.3af, IEEE 802.3az, IEEE 802.1Q, IEEE 802.3at, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3ad, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w
Performance
Internal memory: 128 MB
Flash memory: 32 MB
Buffer size: 512 KB
Mean time between failures (MTBF): 211272 h
Firmware upgradeable: Yes
Packaging data
Package height: 90 mm
Package width: 300 mm
Package depth: 520 mm
Package weight: 3.5 kg
Packaging content
Quick start guide: Yes
Manual: Yes
Cables included: AC
Protocols
Supported network protocols: IPv4/IPv6
Ports & interfaces
Combo SFP ports quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
Gigabit Ethernet (copper) ports quantity: 24
Logistics data
Master (outer) case length: 540 mm
Master (outer) case width: 482 mm
Harmonized System (HS) code: 85176990
Master (outer) case height: 324 mm
Master (outer) case gross weight: 21 kg
Products per master (outer) case: 5 pc(s)
Country of origin: Taiwan
Data transmission
Switching capacity: 52 Gbit/s
Forwarding rate: 38.7 Mpps
Static route: Yes
MAC address table: 8000 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 9600
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 185 W
Power over Ethernet (PoE): Yes
Optical fiber
Fiber ethernet cabling technology: 1000BASE-X
