LevelOne Ultra-Slim RJ45 to SFP Gigabit Media Converter

Features
Plug and Play: Yes
LED indicators: Activity, Link
Internal: No
Product colour: Yellow

Power
Input voltage: 5 V
Power consumption (typical): 1.2 W
Input current: 1 A

Operational conditions
Operating temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 5 - 95%

Weight & dimensions
Weight: 56 g
Height: 18.5 mm
Width: 23.3 mm
Depth: 79 mm

Network
Networking standards: IEEE 802.3z, IEEE 802.3
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
Jumbo frames: 10000
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Jumbo frames support: Yes
Maximum data transfer rate: 1000 Mbit/s
Ethernet LAN data rates: 1000 Mbit/s

Performance
Mean time between failures (MTBF): 100000 h

Packaging data
Package width: 135 mm
Package height: 45 mm
Package type: Box
Package depth: 105 mm
Package weight: 160 g

Packaging content
AC adapter included: Yes
Quick installation guide: Yes

Certificates
Compliance certificates: CE, UKCA, WEEE

Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: SFP
Connectivity technology: Wired

Logistics data
Harmonized System (HS) code: 85176990
Master (outer) case height: 275 mm
Pallet gross length: 80 cm
Master (outer) case width: 475 mm
Master (outer) case length: 560 mm
Master (outer) cases per pallet (air): 15 pc(s)
Pallet height (air): 154.4 cm
Master (outer) case gross weight: 17 kg
Pallet gross width: 120 cm
Products per master (outer) case: 100 pc(s)
Country of origin: China

Sustainability
Sustainability compliance: Yes
