Features Output frequency: 50/60 Hz Waveform: Sine UPS topology: Double-conversion (Online) Output operation voltage (max): 240 V Power factor: 1 Output power capacity: 1 kVA Emergency Power Off (EPO): Yes Audible alarm(s): Yes Input operation voltage (max): 300 V Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm Input frequency: 50/60 Hz Output operation voltage (min): 200 V Input operation voltage (min): 160 V Output power: 1000 W
Design Control type: Buttons Display type: LCD Form factor: Rackmount/Tower International Protection (IP) code: IP20 Product colour: Black
Operational conditions Operating relative humidity (H-H): 0 - 90% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Height: 85.5 mm Weight: 14 kg Width: 438 mm Depth: 445 mm
Packaging data Package type: Box
Packaging content Rack mount kit: Yes Cables included: Input power cable, USB cable Batteries included: Yes Manual: Yes Quick installation guide: Yes
Certificates Compliance certificates: RoHS, CE, Federal Communications Commission (FCC)
Ports & interfaces Serial ports quantity: 1 Emergency Power Off (EPO) connector: Yes Serial interface: Yes USB port: Yes AC outlet types: C13 coupler RS-232 ports: 1 USB port type: USB Type-B Serial interface type: RS-232 AC outlets quantity: 8 AC outlet(s) Ethernet LAN (RJ-45) ports: 1 USB 2.0 ports quantity: 1
Battery Battery capacity: 84 Wh, 7000 Ah Battery recharge time (90%): 3 h Rechargeable battery: Yes Battery voltage: 36 V Battery technology: Lead-Acid Number of batteries included: 3 pc(s)
