Features
Output operation voltage (min): 200 V
Audible alarm(s): Yes
Input frequency: 50/60 Hz
Output operation voltage (max): 240 V
Power factor: 1
Output power: 3000 W
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
UPS topology: Double-conversion (Online)
Output power capacity: 3 kVA
Emergency Power Off (EPO): Yes
Input operation voltage (min): 160 V
Input operation voltage (max): 300 V
Waveform: Sine
Output frequency: 50/60 Hz
Design
International Protection (IP) code: IP20
Display type: LCD
Form factor: Rackmount/Tower
Control type: Buttons
Product colour: Black
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 438 mm
Width: 600 mm
Weight: 26.3 kg
Height: 85.5 mm
Packaging data
Package type: Box
Packaging content
Batteries included: Yes
Cables included: Input power cable, USB cable
Rack mount kit: Yes
Manual: Yes
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC)
Ports & interfaces
RS-232 ports: 1
Serial ports quantity: 1
USB port: Yes
AC outlet types: C19 coupler, C13 coupler
Serial interface type: RS-232
Ethernet LAN (RJ-45) ports: 2
AC outlets quantity: 8 AC outlet(s)
USB 2.0 ports quantity: 1
USB port type: USB Type-B
Serial interface: Yes
Emergency Power Off (EPO) connector: Yes
Battery
Number of batteries included: 6 pc(s)
Battery capacity: 9000 Ah, 108 Wh
Battery technology: Lead-Acid
Rechargeable battery: Yes
Battery voltage: 72 V
Battery recharge time (90%): 3 h
