Design Fan diameter: 13.5 cm Number of fans: 1 fan(s) Product colour: Black Fan speed: 0 - 1300 RPM
Power Input current: 10 A Power protection features: Short circuit, Over voltage, Over power, Under voltage, Over current, Under temperature AC input voltage: 100 - 240 V AC input frequency: 50/60 Hz Max output current (+5Vsb): 3 A Total power: 550 W Max output current (+3.3V): 20 A Combined power (-12V): 3.6 W Combined power (+5V): 100 W Efficiency: 85% Max output current (-12V): 0.3 A Combined power (+12V): 549.6 W Max output current (+5V): 20 A Combined power (+5Vsb): 15 W Max output current (+12V): 45.8 A Power Factor Correction (PFC) type: Active Combined power (+3.3V): 100 W
Weight & dimensions Width: 86 mm Depth: 150 mm Height: 150 mm
Performance Purpose: PC 80 PLUS certification: 80 PLUS Bronze Noise level: 33.2 dB ATX version: 3.1 Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h
Ports & interfaces Floppy disk drive connector: Yes ATX Power connector (24-pin): Yes EPS power connector (8-pin): Yes Cabling type: Non-Modular PCI Express power connectors (6+2 pin): 4 EPS power connector (4+4 pin): Yes CPU power cable length: 65 cm Motherboard power connector: 24-pin ATX CPU power connector (4+4 pin): Yes Number of PATA power connectors: 3 Floppy drive power connector: 1 Motherboard power cable length: 60 cm
