Design Fan speed: 0 - 1600 RPM Number of fans: 1 fan(s) Product colour: Black Fan diameter: 13.5 cm
Power Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A Combined power (-12V): 3.6 W Max output current (+5V): 20 A Combined power (+5Vsb): 15 W Max output current (+3.3V): 20 A Combined power (+5V): 100 W Max output current (+12V): 54.1 A Combined power (+12V): 649.2 W AC input frequency: 50/60 Hz Input current: 10 A AC input voltage: 100 - 240 V Power Factor Correction (PFC) type: Active Combined power (+3.3V): 100 W Power protection features: Over power, Under temperature, Short circuit, Over voltage, Under voltage, Over current Total power: 650 W Efficiency: 85%
Weight & dimensions Height: 150 mm Depth: 150 mm Width: 86 mm
Performance ATX version: 3.1 80 PLUS certification: 80 PLUS Bronze Mean time between failures (MTBF): 100000 h Purpose: PC Noise level: 39.3 dB Power supply unit (PSU) form factor: ATX
Ports & interfaces Floppy drive power connector: 1 CPU power cable length: 65 cm CPU power connector (4+4 pin): Yes EPS power connector (4+4 pin): Yes Motherboard power connector: 24-pin ATX Motherboard power cable length: 60 cm Number of PATA power connectors: 3 Floppy disk drive connector: Yes ATX Power connector (24-pin): Yes EPS power connector (8-pin): Yes PCI Express power connectors (6+2 pin): 4 Cabling type: Non-Modular
