Design Fan diameter: 13.5 cm Number of fans: 1 fan(s) Product colour: Black Fan speed: 0 - 1600 RPM
Power Power protection features: Under temperature, Over power, Under voltage, Over current, Short circuit, Over voltage Combined power (+3.3V): 100 W Efficiency: 85% Total power: 750 W AC input voltage: 100 - 240 V AC input frequency: 50/60 Hz Input current: 10 A Combined power (-12V): 3.6 W Max output current (+12V): 62.5 A Combined power (+12V): 750 W Max output current (+3.3V): 20 A Max output current (+5Vsb): 3 A Combined power (+5V): 100 W Combined power (+5Vsb): 15 W Max output current (+5V): 20 A Power Factor Correction (PFC) type: Active Max output current (-12V): 0.3 A
Weight & dimensions Height: 150 mm Depth: 150 mm Width: 86 mm
Performance Noise level: 40.1 dB ATX version: 3.1 80 PLUS certification: 80 PLUS Bronze Mean time between failures (MTBF): 100000 h Purpose: PC Power supply unit (PSU) form factor: ATX
Ports & interfaces PCI Express power connectors (6+2 pin): 4 EPS power connector (8-pin): Yes ATX Power connector (24-pin): Yes Floppy disk drive connector: Yes Cabling type: Non-Modular Motherboard power cable length: 60 cm EPS power connector (4+4 pin): Yes Motherboard power connector: 24-pin ATX Floppy drive power connector: 1 CPU power cable length: 65 cm CPU power connector (4+4 pin): Yes Number of PATA power connectors: 3
