Design Product colour: Black Number of fans: 1 fan(s) Fan diameter: 13.5 cm Fan speed: 0 - 1600 RPM
Power Combined power (+5Vsb): 15 W Max output current (+5V): 20 A Max output current (+5Vsb): 3 A Max output current (+3.3V): 20 A Max output current (+12V): 83.3 A Power protection features: Under voltage, Over current, Over power, Short circuit, Over voltage, Surge & inrush protection (SIP), Under temperature, No load operation Combined power (+3.3V): 100 W Combined power (+5V): 100 W Combined power (+12V): 1000 W Total power: 1000 W Power Factor Correction (PFC) type: Active AC input frequency: 50/60 Hz Input current: 8 - 15 A AC input voltage: 100 - 240 V
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Width: 86 mm Depth: 150 mm Height: 150 mm
Performance Mean time between failures (MTBF): 100000 h Bearing technology: FDB Power supply unit (PSU) form factor: ATX Purpose: PC 80 PLUS certification: 80 PLUS Gold ATX version: 3.1 Noise level: 36.21 dB
Ports & interfaces Motherboard power cable length: 62 cm PCI Express power connectors (6+2 pin): 2 Cabling type: Fully-Modular CPU power cable length: 70 cm Motherboard power connector: 20+4 pin ATX PCI Express power cable length: 65 cm ATX power connector (20+4 pin): Yes Peripheral (Molex) power connectors (4-pin): 4 Peripheral (Molex) power cable length: 500 mm
