Design Fan diameter: 13.5 cm Number of fans: 1 fan(s) Fan speed: 0 - 2400 RPM Product colour: Black
Power AC input voltage: 100 - 240 V Input current: 8 - 15 A Power protection features: No load operation, Under temperature, Over power, Under voltage, Over current, Short circuit, Over voltage, Surge & inrush protection (SIP) Combined power (+5V): 100 W Combined power (+3.3V): 100 W Max output current (+3.3V): 20 A Power Factor Correction (PFC) type: Active AC input frequency: 50/60 Hz Max output current (+12V): 100 A Combined power (+5Vsb): 15 W Total power: 1200 W Max output current (+5V): 20 A Combined power (+12V): 1200 W Max output current (+5Vsb): 3 A
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Width: 86 mm Height: 150 mm Depth: 150 mm
Performance Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold ATX version: 3.1 Noise level: 36.27 dB Bearing technology: FDB Purpose: PC Power supply unit (PSU) form factor: ATX
Ports & interfaces Cabling type: Fully-Modular Peripheral (Molex) power cable length: 500 mm Motherboard power connector: 20+4 pin ATX PCI Express power cable length: 65 cm ATX power connector (20+4 pin): Yes Motherboard power cable length: 62 cm CPU power cable length: 70 cm Number of SATA power connectors: 12 Peripheral (Molex) power connectors (4-pin): 4 PCI Express power connectors (6+2 pin): 2
