Design Product colour: Black Fan diameter: 9.2 cm Number of fans: 1 fan(s) Fan speed: 0 - 3000 RPM
Power Input current: 5 - 10 A Combined power (+5Vsb): 15 W Max output current (+5V): 20 A AC input voltage: 100 - 240 V Combined power (+3.3V): 100 W Max output current (+12V): 62 A Power Factor Correction (PFC) type: Active Max output current (+3.3V): 20 A Combined power (+5V): 100 W Max output current (-12V): 0.3 A Total power: 750 W Power protection features: Surge & inrush protection (SIP), No load operation, Under temperature, Short circuit, Over voltage, Under voltage, Over current, Over power Max output current (+5Vsb): 3 A Efficiency: 90% Combined power (-12V): 3.6 W Combined power (+12V): 744 W AC input frequency: 50/60 Hz
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Height: 63.5 mm Width: 125 mm Depth: 100 mm
Performance 80 PLUS certification: 80 PLUS Gold Purpose: PC Power supply unit (PSU) form factor: SFX Noise level: 32.5 dB ATX version: 3.1 Bearing technology: FDB
Ports & interfaces EPS power connector (8-pin): Yes Motherboard power cable length: 35 cm Cabling type: Fully-Modular PCI Express power connectors (6+2 pin): 2 Peripheral (Molex) power connectors (4-pin): 1 CPU power cable length: 60 cm SATA power cable length: 350 mm Motherboard power connector: 20+4 pin ATX Peripheral (Molex) power cable length: 350 mm PCI Express power connectors (8-pin): 1 Number of SATA power connectors: 7 PCI Express power cable length: 40 cm
