Design Product colour: Black Number of fans: 1 fan(s) Fan speed: 0 - 3000 RPM Fan diameter: 9.2 cm
Power AC input voltage: 100 - 240 V Input current: 5 - 10 A Power protection features: Over power, Short circuit, Over voltage, Under voltage, Over current, No load operation, Surge & inrush protection (SIP), Under temperature AC input frequency: 50/60 Hz Combined power (-12V): 3.6 W Combined power (+12V): 840 W Combined power (+3.3V): 100 W Power Factor Correction (PFC) type: Active Max output current (+12V): 70 A Max output current (+3.3V): 20 A Combined power (+5V): 100 W Max output current (+5V): 20 A Combined power (+5Vsb): 15 W Max output current (+5Vsb): 3 A Total power: 850 W Max output current (-12V): 0.3 A Efficiency: 90%
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 100 mm Height: 63.5 mm Width: 125 mm
Performance 80 PLUS certification: 80 PLUS Gold Noise level: 40 dB Power supply unit (PSU) form factor: SFX Bearing technology: FDB Purpose: PC ATX version: 3.1
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 1 EPS power connector (8-pin): Yes PCI Express power connectors (8-pin): 1 Peripheral (Molex) power cable length: 350 mm Number of SATA power connectors: 7 Motherboard power cable length: 35 cm SATA power cable length: 350 mm PCI Express power cable length: 40 cm Cabling type: Fully-Modular CPU power cable length: 60 cm PCI Express power connectors (6+2 pin): 2 Motherboard power connector: 20+4 pin ATX
