Design Product colour: White Fan speed: 0 - 3000 RPM On/off switch: Yes Cooling type: Active Fan diameter: 9.2 cm Number of fans: 1 fan(s)
Power Combined power (+5V): 100 W Efficiency: 90% Power protection features: Over power, No load operation, Short circuit, Over voltage, Surge & inrush protection (SIP), Under temperature, Under voltage, Over current Max output current (+3.3V): 20 A AC input voltage: 100 - 240 V Combined power (+12V): 744 W Power Factor Correction (PFC) type: Active Max output current (+5Vsb): 3 A Combined power (+3.3V): 100 W Max output current (+12V): 62 A AC input frequency: 50/60 Hz Combined power (-12V): 3.6 W Input current: 5 - 10 A Combined power (+5Vsb): 15 W Max output current (-12V): 0.3 A Max output current (+5V): 20 A Total power: 750 W
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Width: 125 mm Height: 63.5 mm Depth: 100 mm
Performance Power supply unit (PSU) form factor: SFX Noise level: 32.5 dB Bearing technology: FDB ATX version: 3.1 80 PLUS certification: 80 PLUS Gold Purpose: PC
Ports & interfaces EPS power connector (8-pin): Yes PCI Express power cable length: 40 cm Peripheral (Molex) power connectors (4-pin): 1 Number of SATA power connectors: 7 CPU power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 2 SATA power cable length: 350 mm Cabling type: Fully-Modular CPU power cable length: 60 cm PCI Express power connectors (8-pin): 1 Motherboard power connector: 20+4 pin ATX Motherboard power cable length: 35 cm
