Design On/off switch: Yes Cooling type: Active Product colour: White Fan diameter: 9.2 cm Number of fans: 1 fan(s) Fan speed: 0 - 3000 RPM
Power AC input frequency: 50/60 Hz Total power: 850 W Combined power (+5V): 100 W Efficiency: 90% Combined power (-12V): 3.6 W Power protection features: Surge & inrush protection (SIP), No load operation, Over power, Under temperature, Under voltage, Over current, Short circuit, Over voltage Combined power (+5Vsb): 15 W Input current: 5 - 10 A Power Factor Correction (PFC) type: Active AC input voltage: 100 - 240 V Combined power (+12V): 840 W Combined power (+3.3V): 100 W Max output current (+5V): 20 A Max output current (+12V): 70 A Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A Max output current (+3.3V): 20 A
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 100 mm Width: 125 mm Height: 63.5 mm
Performance Purpose: PC Noise level: 40 dB 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: SFX Bearing technology: FDB ATX version: 3.1
Ports & interfaces Cabling type: Fully-Modular Peripheral (Molex) power connectors (4-pin): 1 EPS power connector (8-pin): Yes Motherboard power connector: 20+4 pin ATX PCI Express power connectors (8-pin): 1 Motherboard power cable length: 35 cm PCI Express power cable length: 40 cm Number of SATA power connectors: 7 CPU power cable length: 60 cm SATA power cable length: 350 mm CPU power connector (4+4 pin): Yes
