Design
On/off switch: Yes
Number of fans: 1 fan(s)
Product colour: White
Fan diameter: 12 cm
Power
Power protection features: Under voltage, Over current, Short circuit, Over voltage, Overheating, Overdischarge, Overcharge, Surge & inrush protection (SIP)
Power factor: 0.95
AC input frequency: 50/60 Hz
Input current: 7.5 - 14.8 A
AC input voltage: 100 - 240 V
Total power: 1200 W
Combined power (+12V): 1200 W
Max output current (+3.3V): 20 A
Combined power (+5V): 100 W
Max output current (+5V): 20 A
Combined power (-12V): 3.6 W
Combined power (+5Vsb): 15 W
Max output current (-12V): 0.3 A
Max output current (+12V): 100 A
Power Factor Correction (PFC) type: Active
Max output current (+5Vsb): 3 A
Combined power (+3.3V): 100 W
Weight & dimensions
Height: 86 mm
Depth: 140 mm
Width: 150 mm
Performance
Purpose: PC
80 PLUS certification: 80 PLUS Platinum
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Bearing technology: FDB
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 1
Cabling type: Fully-Modular
Motherboard power connector: 20+4 pin ATX
ATX power connector (20+4 pin): Yes
PCI Express power cable length: 55 cm
PCI Express power connectors (16-pin): 2
Peripheral (Molex) power cable length: 400, 850 mm, 700, 550 mm
SATA power cable length: 550, 400, 850 mm, 700 mm
Number of SATA power connectors: 2
PCI Express power connectors (8-pin): 3
Motherboard power cable length: 60 cm
EPS power connector (4+4 pin): Yes
