Nominal attenuation: 300KHz~825MHz 5dB, 2.475GHz~4.125GHz 12dB~20dB
Features
Cable material: Copper
Dolby technologies: DTS-HD Master Audio, Dolby TrueHD
Connector 1 gender: Male
Audio Return Channel (ARC): Yes
Cable jacket material: Polyvinyl chloride (PVC)
Connector housing material: Acrylonitrile butadiene styrene (ABS)
Connector material: Gold
Shield material: Aluminium
Colour sampling: 4:4:4
Maximum refresh rate: 60 Hz
Connector 2 gender: Male
HDMI Ethernet channel: Yes
Contact material: Phosphor bronze
Supported video modes: 2160p
Connector 2 form factor: Straight
HDMI version: 2.0
Connector 2: HDMI Type A (Standard)
AWG wire size: 28
Connector contacts plating: Gold
Connector 1 form factor: Straight
Data transfer rate: 18 Gbit/s
Product colour: Black
Bending radius (min): 10 cm
Connector 1: HDMI Type A (Standard)
Cable type: Round cable
Cable length: 10 m
Supported graphics resolutions: 4096 x 2160
Operational conditions
Storage temperature (T-T): -10 - 60 °C
Operating temperature (T-T): -20 - 80 °C
Weight & dimensions
Connector 2 dimensions (WxDxH): 21.68 x 43 x 13.22 mm
Connector 1 dimensions (WxDxH): 21.68 x 43 x 13.22 mm
Cable diameter: 8.6 mm
Packaging data
Quantity per pack: 1 pc(s)
Package type: Polybag
Certification: CE, UKCA, FCC, RoHS, REACH, UL
Certificates
Compliance certificates: RoHS
Logistics data
Harmonized System (HS) code: 84733080
Safety warning
Warnings: Avoid contact of the cable with water or moisture., Avoid bending the cable sharply to avoid damaging the internal wires., Store the cable away from heat sources.
