Features Supported graphics resolutions: 3840 x 2160, 4096 x 2160 Connector 2: HDMI Type A (Standard) Data transfer rate: 10.2 Gbit/s Connector contacts plating: Gold Connector housing material: Polyvinyl chloride (PVC) Cable material: Copper AWG wire size: 24 Product colour: Black, Grey Cable length: 10 m Connector 2 form factor: Straight Cable type: Round cable Dolby technologies: DTS-HD, Dolby TrueHD Cable jacket material: Polyvinyl chloride (PVC) 3D: Yes Connector 1: HDMI Type A (Standard) HDMI version: 2.0 Supported video modes: 2160p Contact material: Phosphor bronze Maximum refresh rate: 60 Hz Connector material: Gold Connector 1 gender: Male Connector 1 form factor: Straight Connector 2 gender: Male Bending radius (min): 9.8 cm Colour sampling: 4:2:0 Shield material: Aluminium
Operational conditions Storage temperature (T-T): -25 - 85 °C Operating temperature (T-T): -20 - 80 °C
Weight & dimensions Cable diameter: 9.8 mm Connector 1 dimensions (WxDxH): 21.4 x 41.44 x 12.7 mm Connector 2 dimensions (WxDxH): 21.4 x 41.44 x 12.7 mm
Packaging data Quantity per pack: 1 pc(s) Package type: Polybag Certification: RoHS, REACH, UL
Certificates Compliance certificates: RoHS
Logistics data Harmonized System (HS) code: 84733080
Safety warning Warnings: Avoid contact of the cable with water or moisture., Avoid bending the cable sharply to avoid damaging the internal wires., Store the cable away from heat sources.
