Features Conductor material: Tinned copper Connector 1: USB A Connector 1 form factor: Straight Connector 2 gender: Female Connector 1 gender: Male Maximum data transfer rate: 5 Gbit/s, 5000 Mbit/s Product colour: Black Connector shield material: Aluminium Connector 2: USB A USB version: USB 3.2 Gen 1 (3.1 Gen 1) Connector material: Nickel Connector contacts plating: Gold Connector 2 form factor: Straight Cable jacket material: Polyvinyl chloride (PVC) AWG wire size: 24/24/20 Connector shielding: Yes Cable type: Round cable Contact material: Brass Connector housing material: Plastic Transmission medium: Twisted pair
Power Power note: 2.5/0.7mm DC
Operational conditions Operating temperature (T-T): 0 - 50 °C Storage temperature (T-T): -20 - 60 °C
Weight & dimensions Cable length: 10 m Weight: 750 g Cable diameter: 7 mm Connector 1 dimensions (WxDxH): 15 x 49 x 8 mm Bend radius (min): 3.6 cm Connector 2 dimensions (WxDxH): 20 x 80 x 13 mm
Packaging data Package depth: 70 mm Package weight: 900 g Package width: 240 mm Package type: Box Package height: 200 mm
Packaging content Manual: Yes Quantity per pack: 1 pc(s)
Logistics data Harmonized System (HS) code: 84733080
