Nominal attenuation: 0.064 MHz, -0.08 dB
0.256MHz, -0.11 dB
0.512MHz, -0.13 dB
0.772 MHz, -0.15 dB
1 MHz, -0.2 dB
4 MHz, -0.39 dB
8 MHz, -0.57 dB
12 MHz, -0.76 dB
24 MHz, -0.95 dB
48 MHz, -1.35dB
96 MHz, -1.9 dB
200 MHz, -3.2 dB
400 MHz, -5.8 dB
Certification: CE, UKCA, FCC, RoHS, REACH, California Proposition 65
Features
Connector contacts plating: Gold
Maximum data transfer rate: 480 Mbit/s, 0.48 Gbit/s
Connector 2 form factor: Straight
Connector 2 gender: Female
Cable jacket material: Polyvinyl chloride (PVC)
AWG wire size: 26/20
Connector 1: USB A
Connector 1 form factor: Straight
Cable type: Round cable
Connector material: Gold/Nickel
Conductor material: Tinned copper
Connector 1 gender: Male
Connector shield material: Aluminium
Product colour: Black
Connector 2: USB A
USB version: USB 2.0
Connector housing material: Plastic
Contact material: Brass
Transmission medium: Twisted pair
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 420 g
Cable diameter: 5 mm
Bend radius (min): 2.6 cm
Cable length: 12 m
Connector 2 dimensions (WxDxH): 20 x 64 x 13 mm
Connector 1 dimensions (WxDxH): 15 x 43 x 8 mm
Packaging data
Package weight: 597 g
Package width: 238 mm
Package type: Box
Package height: 66 mm
Package depth: 202 mm
Packaging content
Quantity per pack: 1 pc(s)
Logistics data
Harmonized System (HS) code: 84733080
