Features Type: Transmitter & receiver Connectivity technology: Wired LED indicators: Power Maximum digital resolution: 3840 x 2160 pixels Material: Metal Colour depth: 8 bit Maximum transfer distance: 150 m Cable types supported: Cat6 Maximum refresh rate: 60 Hz Product colour: Black
Power DC-in jack: Yes Input current: 1 A DC voltage: 24 V
Operational conditions Operating temperature (T-T): 0 - 40 °C Storage relative humidity (H-H): 20 - 90% Operating relative humidity (H-H): 20 - 90% Storage temperature (T-T): -20 - 60 °C
Weight & dimensions Transmitter depth: 6.5 cm Transmitter height: 1.8 cm Transmitter weight: 800 g Receiver width: 14 cm Transmitter width: 14 cm Receiver height: 1.8 cm Receiver depth: 6.5 cm Receiver weight: 800 g
Packaging data Package weight: 1.02 kg Package height: 185 mm Package width: 245 mm Package depth: 75 mm
Packaging content Mounting bracket(s) included: Yes Included power plug types: AU, US, EU, UK Cables included: USB Manual: Yes AC adapter included: Yes
Ports & interfaces USB port type: USB Type-A/USB Type-B RS-232 ports: 2 USB 1.1 ports quantity: 5 Remote (IR) input: 2 Remote (IR) output: 2
Other features Compliance certificates: REACH, Federal Communications Commission (FCC), RoHS, CE, UKCA
Transmitter Transmitter local keyboard/mouse port type: USB Transmitter local video port type: DisplayPort RJ-45 ports quantity (transmitter): 1 Transmitter local video port: Yes Transmitter video port type: DisplayPort
Receiver Receiver local video port type: DisplayPort RJ-45 ports quantity (receiver): 1 Receiver local keyboard/mouse port type: USB Receiver local video ports quantity: 1
